Specifications

Drive Type: Typically available in 6x4 (most common for long-haul) and 6x6 (for off-road and heavy-duty applications).

Gross Combination Weight (GCW): Can vary significantly, often exceeding 90,000 kg depending on the configuration.

Overall Dimensions: Length around 6.8 to 7.0 meters, width around 2.5 meters, and height around 3.7 to 3.9 meters.

Wheelbase: Usually around 3175+1400 mm for 6x4 configurations.

Engine Brands: Weichai

Engine Models:  Weichai WP10

Power Output:  430 hp

Emission Standards: Euro III, Euro V,

Transmission Brand:  FAST Gear

Transmission Type: Manual transmissions with 10 forward speeds and 2 reverse speeds.

Front Axle: Usually MAN technology axles with a capacity of around 7.5 to 9.5 tons.

Rear Axles: Typically MAN technology double reduction axles with a capacity of around 13 to 16 tons per axle.

Chassis and Suspension:

Frame: High-strength steel frame with varying thicknesses depending on the application.

Suspension: Typically leaf spring suspension, with variations in the number of leaves and configuration depending on the load capacity and intended use.

Fuel Tank: Aluminum alloy fuel tanks with capacities ranging from 300 liters

Tires: Usually 12.00R22.5 or 315/80R22.5 tubeless tires.

Braking System: Dual circuit compressed air brakes with ABS

Fifth Wheel: JOST fifth wheel, typically 50# or 90#
