Product Parameters


Truck ModelZZ5317M4667W
Truck BrandSINOTRUK—HOWO
Driving TypeLeft hand driving
Dimension(Lx W x H)(unloaded)(mm)11980x2496x3900
Carriage inner dimension(L x W x H)(mm)9150*2400*1500
Approaching angle/Departure angle(°)19/19
F/R track base(mm)2022/1830
Tank capacity( m3 )30
Gear oil pumpModel76YCB-40(F)
flux m3/h40
In /out caliber mm76
RPM r/min960
Remarks:oil pump model with F, represent relief valve, used for oil tanker truck with oil gun. Fire extinguisher(4kg),Oil pipeline(2.5”, 2*3m),etc
Wheel base (mm)1800+4600+1350
Max speed(km/h)90
Curb weight(kg)16360
Loading Weight(kg)31000
EngineModelWD615.87, Water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection
Fuel typeDiesel
Horse Power290hp
EmissionEURO II
Fuel tanker capacity (L)300
TransmissionModelHW13710CL,10 forwards and 2 reverse
Brake systemService brakeDual circuit compressed air brake
Parking brakespring energy, compressed air operating on rear wheels
Auxiliary brakeEngine exhaust brake
Steering systemModel8198
Front axleHF7
Rear axleST16
ColorOptional
Tire12R22.5
Tire quantity12+1 spare
Electrical systemBattery2X12V/165Ah
Alternator28V-1500kw
Starter7.5Kw/24V
CabHOWO76 cab with one sleeper and air conditioner, all-steel forward control, 55º hydraulically tilt able to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
