Product Parameters

VEHICLE SPECIFICATIONDESCRIPTION
Truck ModelZZ4257V3247
Type of VehicleTRACTOR TRUCK
Truck BrandSINOTRUK—HOWO A7
Driving PositionLeft hand Driving
Fuel tanker capacity(L)400
The Total Mass50,000kg
Dead Weight8800
Max speed(km/h)(km/h)102
ColorOptional
Chassis & Add Components
Frame DetailsHigh-Strength U-profile ladder frame with section of 300*90*8mm and reinforced sub-frame, all cold riveted cross members.
Dimension(Lx W xH)(unloaded)(mm)6985x2496x3850
Approaching angle/Departure angle(°)15/46
Overhang(front/rear) (mm)1540/870
Wheel base (mm)3225+1350
Engine
ModelD12.42
Power420hp/309kw.2000r/min
EmissionEURO II
Displacement(L)11.726
Typewater-cooled,four strokes,6 cylinders in line,turbocharged, directly injection
Kind of FuelDiesel
Clutch & Gear Box System
ClutchSINOTRUKΦ430mm diaphragm spring clutch
Gear Box10 forwards and 2 reverse
Axles
Front Axle ModelHF7 axle. Capacity: 7000kg
Rear AxleST16 axle. Capacity:2X 13000kg
Electrical System
Battery2X12V/165Ah
Alternator28V-1500w
Starter7.5Kw/24V
Brake System
Service brakeDual circuit compressed air brake
Parking brakespring energy, compressed air operating on rear wheels
Auxiliary brakeEngine exhaust brake
Steering system
ModelZF8098
Typehydraulic steering with power assistance
Wheels & Tyres
Type12R22.5
MaterialTubeless tires
Quantity10+1 spare
Kin pin50mm or 90mm
Cabin
TypeA7-G
(high floor with lengthening cabin)double sleeper, with air-condition,4 point full-floating air suspension, adjustable steering wheel with various heights and angles, air suspension seat,etc.
