Product Parameters


Main Description
Overall Dimension13000mm*2495mm*3350mm
Box Body Dimension12780mm*2300mm*1550mm+sidewall 600mm+fence 1000mm+top 200mm
Tare Weight8000kgPay Load40ton
King Pin Setting1460mmRear Overhang1930mm, 2130mm
Track1840mmLoading surface height1600mm
Wheel base7000mm+1305mm+1305mm, 6800mm+1305mm+1305mm
Running Gear
SuspensionTri-axle mechanical suspension with 11-pcs leaf spring
Wheel HubsCast steel, 10 studs
Tires12R22.5, 11.00-20, 11.00R20,12.00-20,12.00R20, 12units
Axles3AQ,FUWA,JSAF, BPW or STEYR axle, load capacity 13T
BrakesDual lines pneumatic brake system, WABCO Emergency Relay Valve; T30/30+T30 air chamber; parking brake
Under Frame
Main BeamI shape, Mild Alloy (16Mn) by Automatic submerged arc welding.
Cross BeamMild Alloy Q235
King PinSize: 50# (2'') or 90#(3.5’’); Type: welded or assembled
Landing GearSingle side operation or double side operation, Static capacity 30Ton
Electrical & Paint
Lights & ReflectorsRear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Wiring24V, 6 lines
Air/Elec. ConnectorISO standard air connector, 24V 7 pin plug socket
PaintSand blasting before painting, 2 coat of anticorrosive primer, 2 coats of finish urethane paint, Color upon request

Product Detail

Factory Showcase

  • 33
  • 22
  • 11
  • 4
  • 5
  • 2

Customer visit

  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8

FAQ

Q1. Are you a factory or a trading company?
A: We are not just a factory, we also have a sales team, our technical team, and an after-sales workshop to help buyers decide which products are their suitable choices, all your inquiries will be replied to within 24 hours.



Q2. Can you send me all your catalogs and price lists?
A: Please tell me the items, sizes, and packages you are interested in so that we can send you the price list you need for your reference.


Q3. What is your delivery time?
A: Generally speaking, delivery time is 10 to 15 days after receiving the payment. The production department will check large quantities. We will deliver the goods as soon as possible while ensuring quality.


Q4. What documents can you provide?
A: We usually provide customers with a commercial invoice, price list, packing list, certificate of origin, quality/quantity certificate, beneficiary certificate, bill of lading, etc., according to their requirements.
