Product Parameters


BrandSinotruck---Howo
Driving Type8*4
Engine max. Output(hp)371hp EURO II
Overall dimension(L*W*H)(mm):11000x2500x3500mm
Body Inside Dimension (L*W*H):7800*2300*1600mm,27cbm
Gross vehicle weight (kg)31000
Thickness of bottom /side plate(mm):7/5
Curb weight of the Chinese dump truck (kg)15480Kgs
Load factor (payload to weight ratio)1
Displacement:9.726L
Hydraulic Lift of CarriageChina middle lift
Wheel base(mm)1800+4200+1350


SteeringZF8098 Steering with doubleT-cross section beam
TransmissionHW19710,10 forward, 2 reverse
Front AxleHF9 drum-type
Rear AxleAC16 gear ratio 5.45
CabHW76, with two seats one bed ,left hand drive,all steel forward control, 55°hydraulically tiltable to the front, 2-arm windscreen wiper system with 3 speeds, laminated windscreen with casted-in ratio aerial, adjustable driver's seat and rigid adjustable co- driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, stereo radio/cassette recorder, safety belts and adjustable steering wheel.4 point support fully floating suspension and shock absorber with tranverse stabilizer.airconditioner.
BumperHigh bumper (metal)
Tyre12.00R20,including one spare tire
Fuel Tank(L)300L
ColorColor by customer’s requirement


Product Detail

Factory Showcase

  • 33
  • 22
  • 11
  • 4
  • 5
  • 2

Customer visit

  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8

FAQ

Q1. Are you a factory or a trading company?
A: We are not just a factory, we also have a sales team, our technical team, and an after-sales workshop to help buyers decide which products are their suitable choices, all your inquiries will be replied to within 24 hours.



Q2. Can you send me all your catalogs and price lists?
A: Please tell me the items, sizes, and packages you are interested in so that we can send you the price list you need for your reference.


Q3. What is your delivery time?
A: Generally speaking, delivery time is 10 to 15 days after receiving the payment. The production department will check large quantities. We will deliver the goods as soon as possible while ensuring quality.


Q4. What documents can you provide?
A: We usually provide customers with a commercial invoice, price list, packing list, certificate of origin, quality/quantity certificate, beneficiary certificate, bill of lading, etc., according to their requirements.
