Product Parameters


 Total Weight  39950 kg  Rated Load  28500 kg
  Tare Weight  9000 kg  Volume  20-75CBM
  Heating system for bitumen trailer  Diesel oil,coal or vapour  Wheel Base  7000+1310+1310 (mm)
 Tyre Specifications  12R22.5-18PR or as customer's requirements  No. Of the Tyres  8/12/16
  Axle Brand  FUWA (BPW,JINSHENG optional)  No. Of the Axles  2/3/4
  Axle-load  24000 kg  King Pin  50#/90#
  Landing Leg  28ton  Pieces of leaf-spring  10(8)
  Suspension  Independent stamping steel rigid suspension  Departure Angle  14.8
  (or air suspension)
  Front/Rear Overhang  2080 mm  Outside Dimensions (mm)  13000X2500X3800  (LxWxH)
  (Interior )Tank shell Dimensions  (mm)  12800×2500×2300  (LxWxH)   Material of the Main BeamQ345B manganese plates, automatic submerged arc welded
  Brake System  Dual line braking system /ABS  Brake Air Chamber  Six double chamber
  Electrical  24V  7 ways(7 wire harness)  Compartment No & ValveCompartments is depends on the requirements. with loading and unloading valves, loading and unloading pump.

1. High-strength tank material: The tank is made of high-quality stainless steel, carbon steel, aluminum and other materials, which can be ordered according to customer selection, and all are strictly

screened and tested. The material is pressure-resistant, impact-resistant and corrosion-resistant, ensuring that the tank is not corroded when transporting different materials, ensuring the purity and

safety of the materials.


2. Accurate tank structure design: Optimize the structure according to material characteristics and transportation requirements. The liquid material tank is equipped with a reasonable head and

wave-breaking plate to disperse pressure, reduce shaking, and stabilize the center of gravity; the powder material tank is equipped with a fluidizing device to ensure smooth loading and unloading.


3. Humanized loading and unloading system design: The tank truck is equipped with an advanced humanized loading and unloading system. The quick connection interface is easy to operate,

shortens the loading and unloading time, and has good sealing and leakage prevention, ensuring environmental and personnel safety. Some can be equipped with an automated system to

improve efficiency.


4. Good thermal insulation performance: For temperature-sensitive materials, the tank truck can be equipped with a professional thermal insulation layer, and advanced materials can be used

to control the temperature and ensure the quality of the materials.


5. Product transportation: Liquid tank trucks can transport corrosive chemicals and organic reagents such as sulfuric acid; food-grade liquids such as milk and cooking oil; gasoline, asphalt and

other liquids in the energy field.



Product Detail

Factory Showcase

  • 33
  • 22
  • 11
  • 4
  • 5
  • 2

Customer visit

  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8

FAQ

Q1. Are you a factory or a trading company?
A: We are not just a factory, we also have a sales team, our technical team, and an after-sales workshop to help buyers decide which products are their suitable choices, all your inquiries will be replied to within 24 hours.



Q2. Can you send me all your catalogs and price lists?
A: Please tell me the items, sizes, and packages you are interested in so that we can send you the price list you need for your reference.


Q3. What is your delivery time?
A: Generally speaking, delivery time is 10 to 15 days after receiving the payment. The production department will check large quantities. We will deliver the goods as soon as possible while ensuring quality.


Q4. What documents can you provide?
A: We usually provide customers with a commercial invoice, price list, packing list, certificate of origin, quality/quantity certificate, beneficiary certificate, bill of lading, etc., according to their requirements.
